Wilbur Curtis TCC3S - Manual (Page 7)

7
5
6
1
2
3
4
27
17
19
18
7
8
9
10
11
12
13
15
16
14
WATER INLET
PARTS ON
PAGE 8
11
12
13
14
15
16
17
18
19 WC-4320*
WC-1829*
WC-37312
WC-43084*
WC-29069
DTP-08*
WC-14022
WC-2219*
WC-53113* O’ RING, .487 ID X .103 CS
FAUCET, ASSY TCCS BLACK
KIT, ADJUSTING ROD & O’RING
O-RING, .070” ID X .070”W BUNA-N
ROD, ADJUSTABLE MIXING VALVE
DRIP TRAY, 8”
CLAMP, TUBING 15.3-18.5mm SS OETIKER
Y’FITTING BARB ¼x¼x¼ WHT NYLON
TUBING, .25” ID X .50” OD BRAID SILICONE
DESCRIPTION PART Nº ITEM Nº
* RECOMMENDED PARTS TO STOCK
ILLUSTRATED PARTS
TCC3S
ALL PARTS ARE IDENTICAL TO TCC2S,
EXCEPT WHERE NOTED
