Page 3
3
Tea Dilut. Volume
Tea Dilut. Time
Tea Dilut. Delay
Tea By Volume
Tea By Time
Tea by Volume: Scroll until Brew by Volume is displayed. Press to Select. The display will read Select Brew But-
ton! Once the desired brew button is selected (COFFEE or TEA), the display will read Press BREW to Start 0:00 Time.
Press the FULL BREW button and hot water starts dispensing. When the desired volume is reached, press FULL BREW
again to stop the flow. The brew volume has now been set (HALF BREW will always be half of the FULL BREW volume).
When EXIT is displayed, Press to select and exit the programming mode. Pressing > button will display the subse-
quent menu features.
Tea by Time. (Factory set to 5:52 Full Brew, 2:56 Half Brew) Press to Select. Press < or > to increase or decrease
time. Tea by Time has a range of 0:00 to 9:59 (Increments are minutes and seconds). The HALF BREW button will be set
at half the brew time.
Dilution Delay: (Factory set to 30 sec Full Brew, 30 sec Half Brew) Press to Select. Press < or > to toggle between
Standard-Gray (30 sec), Standard-Purple (30 sec), Tropical-Gray (9 min), Tropical-Purple (9 min), 76/308-Gray (4 min)
and 76/308-Purple (4 min). Range is from 0 seconds, 1 minute to 10 minutes.
Dilution Volume: Press to Select, Display will now show Push START To Begin... Press the BREW button then water
starts running, when desired volume is reached press BREW button again to stop the flow. Now the volume has been set.
Pressing > button will display the subsequent menu features.
Dilution Time: (Factory set to 4:05 Full, 2:02 Half) Press to Select. Press < or > to toggle between Standard-Gray
(4min-5sec), Standard-Purple (4min-5sec), Tropical-Gray (4min-26sec), Tropical-Purple (4min-26sec), 76/308-Gray
(4min-55sec) and 76/308-Purple (4min-55sec). Dilution Time is from 30 sec to 9 min, 59 sec.
Tea Dilution Stir (Factory set to Standard – Purple On).
Press to Select, press < or > for a choice of Standard-Gray: On, Standard-Purple: On, Tropical-Gray-Off, Tropical-
Purple-Off, 76/308-Gray-Off and 76/308-Purple-Off. Dilution Stir applies only to the Dilution cycle, by pulsing the dilution
time 45 seconds on, 5 seconds off.
Tea Pulse Brew (Factory set to OFF).
Press to Select, press < or > to choose ON/OFF or D (manual programming). D will give you a pulsing spray of 1-20
pulses on and off at 5 second increments, depending on the total time set for brew (see Tea by Time).
Tea Fast Brew (Factory set to OFF).
Press to Select, press < or > to choose ON or OFF. Selecting ON will start hot water spraying in the brew cone first
and then 1 minute later the dilution water will start to flow.
Coffee by Volume: (Factory set to 60 oz Full Brew, 30 oz Half Brew) Press to Select, Display will now show Push
START To Begin... Press the FULL BREW button then hot water starts running, when desired volume is reached press
FULL BREW button again to stop the flow. Now the volume has been set (HALF BREW will always be half of the FULL
BREW volume).
Coffee by Time (Factory set to 2:25 Full Brew, 1:12 Half Brew). Press to Select to change the brew time. Display
will now show the current time. By pressing < or > you can toggle back and forth from minutes to seconds to exit (ex).
Change the time or set and exit by pressing .
Pre-Infusion (Factory set to OFF)
Press to Select. Current setting in seconds is displayed < to decrease or select > to increase (range from OFF to 10
through 60 seconds), to set.
If Pre-infusion is selected (ON), Cold Brew Lock is set to Delta 1 within 5ºF of set point and Cold Brew Lock disappears
from the list of program selections. When Pre-infusion is ON, Pulse Brew disappears from the list of program selections.
Pulse Brew (Factory setting OFF)
Press to select, < or > to select OFF or one of five pulse patterns (A to E) .
Guidelines for Pulse Brew:
This feature allows tuning of the coffee flavor. This option should only be used with the standard Gray or Purple AFS
sprayheads. The pot level should always be set first with this option OFF. Depending on your grind profile and water
Tea Dilution Stir
Coffee By Time
Coffee By Volume
Coffee Pre-infusion
Tea Pulse Brew
Tea Fast Brew
Coffee Pulse Brew
Continued on Page 4
Program Menus
