www.petsafe.net 7
Components
Boundary Flags - 50
Power
Adapter
Boundary Wire - 500 ft.
Wire Nuts
1
A B
10
2
5 6
7
8
9
4
3
Mounting
Anchors
Mounting
Screws
Test Light
Tool
Gel-filled
Splice Capsules
Receiver
Collar w/Short
Contact Points
Fence Transmitter
Contact Point
Wrench
Long
Contact Points
Operating and
Training Guide
Transmitter &
Surge Protector
Labels
Surge
Protector
(USA & Canada only)
Receiver
Charger
(6 ft.)
Red
Black
Loop Righ t
Loop Left
TX Left
TX Right
402-027
Red
Black
Loop Right
Loop Left
TX Left TX Right
After verifyin g Receiver C ollar operation a t the bound ary, use the labels to ide ntify the Bo undary Wire connection s to the Tra nsmitter an d
the Bounda ry Wire con nections to the Surg e Protector. This will be convenient to have sh ould any of the
wires beco me disconn ected.
Use on Transmitter Connection s
Use on Surge Protector Connection s
yardmax
™
recharg
eable in
-ground
fence
™
operating and tra ining gu ide
PLEASE READ T HIS EN TIRE G UIDE BE FORE B EGINN ING
1 A B 10
2
5 6 7 8 9
4 3
Model Nu mber PIG00-1
1115
Other Items You May Need
• Additional wire and flags (Part # PIG00-13769)
• Tape measure
• Small Phillips screwdriver
• Drill
• Spade shovel or lawn edger
• Pliers
• Wire stripping pliers
• Scissors
• Lighter
• Electrical Tape
• Additional wire nuts and gel-filled splice capsules
• Waterproofing compound (e.g. silicone caulk)
• PVC pipe or water hose
• Circular saw with masonry blade
• Staple gun
• Non-metallic collar and leash
• Temporary marking paint
Fence installation and training help: www.petsafe.net
Want professional installation help? Invisible Fence
® Brand installers will come to your home and install your new
PetSafe ® System for an additional cost. Contact your local dealer at 1-877-866-DOGS (3647) or visit our website at
www.invisiblefence.com for more information.
