Outdoor Great Room Patio Pergola User Manual
Page 9
J
B
1.
Position short crossbeams and secure with bolts L and “L” brackets as shovn.
2. Screw metal brackets J to supplied decorative beam extensions as shown with wood screws O.
3. Secure decorative extensions with screw diagonally from below as shown.
4. If using drop-in lattice these can be placed at this time. Either screw in or leave loose for easy removal
5. Check all bolts and tighten securely.
6. Check for squareness , then bolt post plates to surface.
Screw
L
I
Installation of Short Crossbeams and Decorative Beam Extensions
(Optional lattice installation )
