Outdoor Great Room DIY Fire Pit - Manual

90246 REV C 6/10/13 1
DIY Gas Fire Pits
Assembly and Installation instructions for Natural Gas DIY-38, DIY-2032, DIY-2049
Thank you for purchasing a Do-It-Yourself gas fire pit kit from The Outdoor GreatRoom Company. Please read through all
instruction steps and warnings before assembling your fire pit.
Included in your DIY kit
DIY-2032 (Rectangular) DIY-2049 (Long Rectangular) DIY-38 (Round)

Burner

Electronic igniter

Metal flex hose

4-piece DIY burner support

(8) Nut, bolt , lock washer

(2) Black #6 – 5/8” screws

#31 Orifice (NG)

#43 Orifice (LP)

Control panel with mounting
bracket and optional filler.

Grounding wire

Sparker extension wire

Burner

Electronic igniter

Metal flex hose

6-piece DIY burner support

(12) Nut, bolt , lock washer

(2) Black #6 – 5/8” screws

#21 Orifice (NG)
 #31 Orifice (LP Over 100lb tank)

Control panel with mounting
bracket and optional filler.

Grounding wire

Sparker extension wire

Burner

Electronic igniter

Metal flex hose

4-piece DIY burner support

(8) Nut, bolt , lock washer

(2) Black #6 – 5/8” screws

#17 Orifice (NG)
 #36 Orifice (LP over 100lb tank)

Control panel with mounting
bracket and optional filler.

Grounding wire

Sparker extension wire
Recommended tools and supplies

2 adjustable wrenches for tightening gas connections

7/16” wrench for assembling burner support

Power drill with Phillips bit

AAA Battery for igniter (not included)

Lava rock or other decorative media* (sold separately)

Masonry block

Outdoor-rated construction adhesive for securing block and control panel (if desired)

Leveling device for placing block

Concrete chisel

¼” concrete anchors (optional for attaching control panel bracket to block)

Hammer drill (for drilling holes for concrete anchors)
*lava rock, heat-tempered glass, or other decorative fire-safe medium MUST be used to ensure proper
burner operation. Do not burn without covering burner with lava rock or similar.
Consult your Crystal Fire Owner’s manual included in
this kit for important safety and other information
before operating this burner.
NOTE: If using a 20lb propane tank, an LP kit is available for purchase
on page 5 of this instruction booklet.
Dimensions for recommended
fire pit sizing located on page 5
GAS-FIRED
