Outdoor Great Room Patio Pergola User Manual
Page 6
3” Corbel Screvs
2” Corbel Screvs (M)
K
A
G
D
H
Assembly of Outer Beam and Posts
Note: This step is easier if parts are laid on flat surface for assembly
1. Lay out all pieces to be assembled.
2. Screw corbels (G) to tops of 2 posts.
3. Bolt feet (H) to the bottom of each post.
4. Screw beam (D) to corbels (G).
NOTE: Handle carefully as this assembly is
fragile until full assembly is complete.
