FORM NO. L-21198-A-1204 6
Table 2 Jig Mounting Bolts
RPS Model Bolt Type Tightening Torque
RPS16
M6 5 Nm [44.3 in-lb]
M8 8 Nm [70.8 in-lb]
RPS20
M8 8 Nm [70.8 in-lb]
M10 12 Nm [106.2 in-lb]
RPS25
M10 28 Nm [247.8 in-lb]
M12 30 Nm [265.5 in-lb]
RPS32
M10 28 Nm [247.8 in-lb]
M12 30 Nm [265.5 in-lb]
RPS40
M10 32 Nm [283.2 in-lb]
M12 35 Nm [309.8 in-lb]
Table 1 Rack Mounting Bolt Tightening Torque for Socket Head Cap Screws
RPS Model Bolt Type
Mounting Material
Steel Cast Iron Aluminum
RPS16 M8 31 Nm [274.4 in-lb] 20 Nm [177.0 in-lb] 15 Nm [128.3 in-lb]
RPS20 M10 68 Nm [601.9 in-lb] 45 Nm [398.3 in-lb] 33 Nm [292.1 in-lb]
RPS25 M12 120 Nm [1062.1 in-lb] 78 Nm [690.4 in-lb] 58 Nm [513.3 in-lb]
RPS32 M12 120 Nm [1062.1 in-lb] 78 Nm [690.4 in-lb] 58 Nm [513.3 in-lb]
RPS40 M16 196 Nm [1734.7 in-lb] 131 Nm [1159.4 in-lb] 98 Nm [867.4 in-lb]
Rack Mounting Bolt Tightening Torque for Stainless Steel Screws
RPS Model Bolt Type
Mounting Material
Steel Cast Iron Aluminum
RPS16 M8 19 Nm [168.2 in-lb] 19 Nm [168.2 in-lb] 15 Nm [128.3 in-lb]
RPS20 M10 41 Nm [362.9 in-lb] 41 Nm [362.9 in-lb] 33 Nm [292.1 in-lb]
RPS25 M12 70 Nm [619.6 in-lb] 70 Nm [619.6 in-lb] 58 Nm [513.3 in-lb]
RPS32 M12 70 Nm [619.6 in-lb] 70 Nm [619.6 in-lb] 58 Nm [513.3 in-lb]
RPS40 M16 137 Nm [1212.6 in-lb] 131 Nm [1159.4 in-lb] 98 Nm [867.4 in-lb]
