2.2 Dimensions
Figure 2-2
Hoist Dimensions (See
Table 2-3
)
Table 2-2
Hook Dimension*
T = Top Hook
B = Bottom Hook
Units = inch
Capacity Code
Hook
a
b
c
d
e
g
T
1.1
0.7
0.9
0.7
1.4
1.1
001H, 003S, 003H,
005L, 005S
B
1.1
0.7
0.9
0.7
1.4
0.9
010L, 010M, 010S
T & B
1.4
0.9
1.2
0.9
1.7
1.2
T
1.9
1.1
1.6
1.1
2.0
1.5
015S
B
1.7
1.0
1.4
1.0
1.9
1.3
020S, 020M, 020L
T & B
1.9
1.1
1.6
1.1
2.0
1.5
T
2.2
1.4
1.9
1.4
2.4
1.7
025S
B
2.0
1.2
1.7
1.2
2.1
1.6
030C, 030L, 030S
T & B
2.2
1.4
1.9
1.4
2.4
1.7
050L
T & B
2.6
1.7
2.2
1.7
2.5
1.8
*Refer to
Section 5.7
for inspection dimensions and limits.
