iagnostics

The Dell Diagnosties that eame with your Dell Latitude
eomputer ineludes tests that help you troubleshoot the
eontrollers in your C/Port APR.

The subtests in the Network Interfaee Test Group of the
Dell Diagnosties verify the basie operation of the net

work eontroller in the C/Port APR. They test the

eontroller’s internal funetions, ineluding read and write
aeeess to its registers and internal transmit and reeeive

(loopbaek) eapability.

The subtests in the Serial/Infrared Ports Test Group
eheek the C/Port APR’s interfaee with external deviees

(sueh as a serial mouse or a printer). The subtests in this test

group are not intended as a diagnostie test for the external
deviee itself.

The subtests in the USB Test Group eheek the C/Port

APR’s interfaee with external deviees (sueh as a mouse).

The subtests in this test group are not intended as a diag-

nostie test for the external deviee itself.

For eomplete instruetions on using the Dell Diagnosties,

see Chapter 4, “Running the Dell Diagnosties,” in the

Reference and Troubleshooting Guide

that aeeompanied

your eomputer.

Getting Heip

If you do not understand a proeedure deseribed in this
doeument, or if your C/Port APR does not perform as

expeeted, you ean eall Dell for teehnieal assistanee. Use

the appropriate telephone number found in the “Contaet-

ing Dell” seetion of the eomputer’s online System User’s

Guide

or in Chapter 5, “Getting Help,” of the Reference and

Troubleshooting Guide

that aeeompanied your eomputer.

ecKnicai Specifications

Table 1-1 lists the teehnieal speeifieations for the C/Port

APR.

Tabie 1-1. Technicai Specifications

Physical

Height:

With doeking eontrol base and

monitor stand............................... . . . . 95.6 mm (3.76 inehes)

With doeking eontrol base only. . . . . . 55.2 mm (2.17 inehes)

With short alignment tray ........... . . . . 54.8 mm (2.15 inehes)

Standalone................................... . . . . 49.9 mm (2.00 inehes)

Depth:

With doeking eontrol base and

monitor stand............................... . . . . 475.8 mm (18.73 inehes)

With doeking eontrol base only. . . . . . 475.8 mm (18.73 inehes)

With short alignment tray ........... . . . . 206.7 mm (8.14 inehes)

Standalone................................... . . . . 127.4 mm (5.01 inehes)

NOTE: For the full name of an abbreviation or acronym used in this table, see the Glossary in the

online System User’s Guide.

Dell Latitude C/Port Advanced Port Replicator User’s Guide 1-9
