Welch Allyn 767 Mobile Aneroid Stand Conversion Kit (With Or Without Weight) 95P348 - Installation Guide - Manual (Page 2)

For 767 Mobile Aneroid Units
- to add Weight Option:
1. Position mobile aneroid unit on side.
2. Remove bottom screw from base with
flat and lock washers.
3. Install weight with large recess on
bottom - hold in place and secure with
long hex bolt and washers provided.
BASE
1P330
WHEEL
59P591
LOCK WASHER
22P1442
WEIGHT
98P1
FLAT WASHER
22P1440
BOLT
1INCH = 9P2829
2.5 INCH = 9P2830
(FOR WEIGHT OPTION)
For 767 Mobile Aneroid Units
- to add Weight Option:
1. Position mobile aneroid unit on side.
2. Remove bottom screw from base with
flat and lock washers.
3. Install weight with large recess on
bottom - hold in place and secure with
long hex bolt and washers provided.
BASE
1P330
WHEEL
59P591
LOCK WASHER
22P1442
WEIGHT
98P1
FLAT WASHER
22P1440
BOLT
1INCH = 9P2829
2.5 INCH = 9P2830
(FOR WEIGHT OPTION)
