• This quick start guide is intended for use with CardioPerfect
Workstation Version 1.6.0 or higher.
• For complete directions for use and warnings, please consult
your user manual located on the software CD.
• Install two fresh AA batteries in the back of the ABPM 6100 recorder.
• Connect the PC interface cable to the serial port on the back
of the computer.
• Connect the other end to the bottom of the ABPM 6100 recorder.
If you are using a USB port:
• Install the Keyspan USB to serial converter software first,
then plug in the adapter.
1 Install software
2 Set up monitor
If you are using a USB port:
• Go to Start/Programs/Keyspan USB Serial Adapter.
• Select Keyspan Serial Assistant.
• Verify which COM port was
assigned to adapter.
Start the CardioPerfect Workstation Software:
• Go to File/Settings/ABPM.
• Select Advanced.
• Match proper COM port to Keyspan
Serial Assistant.
3 Communicate with your monitor
• Click on the ABP Icon.
• You will hear a few beeps followed by the New ABP Test window.
• Select Protocol, Referring Physician, etc. and click OK.
• The recorder is now programmed with the patient information
and will turn itself off. Disconnect the monitor from
the computer.
5 Program your monitor
4 Select Patient
• Open the CardioPerfect Workstation Software by
double clicking on the CardioPerfect icon.
• To enter a new patient:
1. Click the Patient button.
2. Fill in Patient Card.
• To select a patient from the database:
1. In the Search box, type the patient name or number (can be a partial entry).
2. Click the Go button.
3. Click on the patient for whom you want to record the test.
