• Height. Touch the OK button.
• Weight. Touch the OK button.
6. Touch the (Next) button.
7. Attach the leads to the patient.
Note If the lead-status screen is closed, touch the (torso)
button to enlarge the lead-status screen.
Any flashing dots on the lead-status screen indicate unattached or poorly attached
leads.
When all leads have been attached for several seconds, the ECG preview screen
appears.
Item Button
1 Leads button
2 Gain button (size)
3 Speed button
4 Filters button
12 Performing an Auto ECG test CP 150 12-lead resting electrocardiograph
