ECG home screen
The ECG home screen includes the following areas:
Item Area
1 Device status
2 Content
3 Navigation
Device status area
The Device status area, located at the top of the ECG home screen, displays:
•
Time and date
• Battery status
• Error or information messages. These items are displayed until the condition has
been resolved.
Content area
The Content area includes 3 test selection buttons and a preview selection button:
7
