Operators guide
35
Parts list
The following lists include main assemblies, user-replaceable spares and optional accessories.
For further information regarding repair or spare parts, please contact Vinten Radamec or your
local Vinten Radamec distributor.
Main assemblies
Fusion FHR-120 robotic pan and tilt head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V4030-0003
Fusion FHR-120 VR robotic pan and tilt head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V4036-0001
Fixing bolts (4 off). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . L054-714
Washers (for fixing bolts, 4 off). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . L602-122
Spanner (for fixing bolts) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J551-001
Fusion FVR box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V4078-1001
FVR interface cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V3990-5213
User-replaceable spare parts
Fuse 6.3/AT ceramic time delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-0168-0020
Optional accessories
Heavy-duty Quickfix ® adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3490-3
Intermediate plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3384-11
Configuration tools
USB system configuration cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D200-103
Fusion Robot Control configuration software (Vincon) . . . . . . . . . . . . . . . . . . . . . . . V3952-8000
Cabling
Contact Vinten Radamec or your local Vinten Radamec distributor for information about our range
of studio floor cables, camera lens cables for use with the Fusion head and Head communication
cable to allow direct connection to a Fusion pedestal or height drive.
