14
(1) Touch screen
(2) On air (Tally) indicators
(3) Pan follow button
(4) Joystick enable button
(5) Bumper disable button
(6) Target disable button
(7) Panel disable button
(8) Backup link button
(9) Camera zoom/pan and tilt head control joystick
(10) Camera preview buttons
(11) Cut to shot button
(12) Fade to shot button
(13) Stop button
(14) Fade time control
(15) Camera focus control
(16) Pedestal control joystick
(17) Power switch
(18) USB ports
Fig 1 FCS-16 Fusion Control System
(1)
(5)
(2)
(6) (7)
(4)
(8) (9) (10) (11) (12) (13)
(14)
(15)
(16)
(17) (18)
(3)
