13
Technical data
Weight
FCS-16 Fusion Control System (including touch screen monitor and PC module) 7 kg (15.4 lb)
PC module 0.5 kg (1.1 lb)
Touch screen monitor (10.4”) 1.7 kg (3.3 lb)
Height
FCS-16 panel (including PC module and joysticks) 24.2 cm (9.5 in.)
Touch screen monitor (10.4”) 19.2 cm (7.5 in.)
Length
FCS-16 panel (including PC module and joysticks) 48.3 cm (19 in.)
Touch screen monitor (10.4”) 25 cm (9.84 in.)
Width
FCS-16 panel (including PC module and joysticks) 17.8 cm (7 in.)
Touch screen monitor (10.4”) 3.8 cm (1.5 in.)
Maximum power consumption 70 W
Input voltage Autoranging 90-264V AC 47/63 Hz
System fuse 5 Amps
Operating temperature 0 - 40°C (32 - 104°F)
User ports 4 x top mounted USB 2.0
2 x bottom mounted USB 2.0
Keyboard USB
Mouse USB
Control capacity 16 camera units
Further information
For further information regarding this Lightweight control panel, please contact Vinten Radamec (see back cov-
er), or visit our website.
For full details on maintenance and spare parts, please refer to the Vinten Radamec FCS-16 Fusion Control
System Technical Manual and Illustrated Parts List - Publication Part No. V4035-4990. This is obtainable from
Vinten Radamec. For information on-line, visit our website at
www.vintenradamec.com
