www.whisperkool.com | Page 19

Alarm

The alarm symbol is shown and an audible buzzer will sound when the unit encounters an issue that

needs attention. The displayed alarm codes are explained below. To silence the buzzer, press any

button. The alarm code will remain displayed until corrected.

Alarm Codes

Message

Cause

Solution

“E1”

Bottle probe is unplugged

Attach bottle probe to unit

Faulty bottle probe connection

1. Check bottle probe attachment at circular connector

2. Check bottle probe connection at the back of controller

Defective Bottle Probe

Replace the bottle probe

“E2”

Faulty Evaporator Probe

Connection

Check evaporator probe connection at the back of controller

Defective Evaporator Probe

Replace the Evaporator Probe

“E3”

Faulty Condenser Probe

Connection

Check the condenser probe connection at the back of the controller

Defective Condenser Probe

Replace the Condenser Probe

“AH1”

The bottle probe is sensing a

temperature that is 4° above the

set point

1. Allow time for the wine to reach the desired temperature

2. Make sure all windows and doors are closed and have a proper seal

3. Follow the procedures in the pre-installation instructions to test the unit for proper

cooling

“AL1”

The bottle probe is sensing a

temperature that is 4° below the

set point

1. Make sure unit is not in cooling mode (the snowflake symbol will not be lit).

2. Add heat to the room until the wine reaches the desired temperature.

“COH”

The condensing unit

temperature is above 145°F

1. Check the condenser coil and clean if necessary.

2. Make sure the room to which the unit is exhausting is not more than 85°F.

3. Make sure both condenser fans are working properly.

“Ad3”

Anti-Frost ended on time-out

1. Check the evaporator coil for ice buildup. Unplug the unit and allow the coil to thaw

before re-starting.

2. Make sure the room to which the unit is exhausting is not less than 60°F.

3. If the unit continues to go into continuous Anti-Frost cycles (every 5 minutes), call

Customer Service for more troubleshooting information.

CPSM (Customer Preference Selection Mode)

Press and hold the “SET” button for approximately 5 seconds to enter the CPSM menu.

“Fdc” will be displayed on the screen. Use the down arrow to access the following parameters.

Fdc

Humidity Management/

Enhancement

This parameter is set to 1 from the factory, which should provide adequate relative humidity for the cellar. An

increase in this parameter will increase the Humidity Enhancement (%RH). This parameter should not be adjusted

below 1. Adjustments should be made in increments of 5, with a maximum of 15 and a minimum of 1. After any

adjustment to Humidity Enhancement, wait a minimum of three days before making any additional adjustments.

This will allow the cellar sufficient time to acclimate to the new setting.

PA2 There are no adjustable settings in this parameter.

tab There are no adjustable settings in this parameter.

Rel There are no adjustable settings in this parameter.

loc Change this parameter from “n” to “y” to lock the keyboard from changes to the set point.

ddd

Select one of these numbers to display your preference:

0 = Set Point

1 = Bottle Probe Temperature

2 = Evaporator Probe Temperature

3 = Condenser Probe Temperature

“CA1”

Use this parameter to calibrate the bottle probe to a known temperature. This parameter can be adjusted

between -12°F and 12°F.

Example: Bottle temperature reading = 58°F

Known temperature reading = 55°F

CA1 parameter setting to match known temperature = -3
