TEST THE UNIT PRIOR TO INSTALLATION
To prepare the unit for testing before installation in wall:
• Unit needs to be in the upright position for 24 hours before starting
• Remove unit from box
• Place unit on tabletop
• Plug in unit to electrical outlet
• Plug in bottle probe
• Turn on to test for approximately 20–30 minutes (temperature across the coil should be 10°F–15°F)
• Turn off after test
• Disconnect bottle probe
Electrical Needs
The WhisperKOOL Unit requires a dedicated 115 volt 20 amp circuit. The unit draws a large amount of amps
at initial start up. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run
effectively. Contact an electrician for assistance with the installation of this dedicated electrical circuit:
• Match the electrical outlet to the plug provided on the WhisperKOOL unit.
• Provide a dedicated circuit and wiring for the unit.
• Provide a weatherproof plug for units connected outside.
Plug your WhisperKOOL unit into a surge protector or power conditioner. As with any sensitive electrical equipment,
the WhisperKOOL electrical equipment may be damaged by power surges and spikes. Power surges and spikes are not
covered under warranty.
WE RECOMMEND THAT YOU DO NOT USE A GFI (GROUND FAULT INTERRUPTER) WITH THIS PRODUCT.
Electrical Inlets
The unit is equipped with two power inlets. One is located on the right side of the unit, (inside of the cellar) the other
is located on the rear of the unit (outside of the cellar). Use the selector switch located on the right side of the unit to
select which power inlet you would like to utilize. If you would like to plug the unit into a socket outside of the cellar,
set the selector switch to rear. If you would like to plug the unit into a socket inside of the cellar, set the selector switch
to the front position. When placed in either position, power can only enter the unit utilizing the power inlet you’ve
selected.
In case the unit should lose power, check the home/main circuit breaker. If the unit does not respond properly, refer to
the Troubleshooting Guide.
PRE-INSTALLATION
FRONT
REAR
Power Inlet
Front/Rear
Power Switch
