Technical specifications
Voltage
Inlet pump consumption (single system)
Electrovalve consumption (centralized system)
Max outlet pump consumption
Main supply fuse (red +)
Inlet pump
Outlet pump
Inlet pipe
Outlet pipe
Max head outlet
Max distance outlet
12V dc
2,4 A
5 A
25 A
40 A
capacity 8 lt/min
centrifugal capacity 350 lt/min
1/2”
internal diameter mm. 40
11 meters
90 meters
24V dc
1,8 A
2,44 A
15 A
30 A
ATTENTION
THE BOWL IS ABLE TO DISCHARGE ONLY
ORGANIC RESIDUALS AND TOILET PAPER
DETERSIVES DO NOT DAMAGE OUTLET PUMP
Close the inlet and outlet safety hand valves when the toilet is not used
Advised pump features for centralized system (not supplied)
Pressure
Delivery
Minimum
1 bar
15 lt/min
Maximum
3 bars
50 lt/min
