- 1 -
UK
Instructions for use
UK
PARTS
a. Removable seat and cover.
b. Swivelling toilet bowl.
c. Valve blade handle.
d. Flush button.
e. Waste tank level indicator: warning light illuminates
when the waste tank requires emptying.
f. Rotating emptying spout: ensures that the waste tank
can be easily and hygienically emptied.
g+h.Automatic pressure release vent: ventilates the waste
tank when this is inserted into the cassette toilet.
Avoids excessive pressure build up in the waste tank.
N.B. A black hose is attached to the automatic pressure
release vent on some toilets. This hose transports the
air to the outside through an access door or through
the floor.
i. Upper handle.
j. Cover guarantees optimal hygiene. Opens when the
waste tank is inserted into the toilet and closes when
the waste tank is removed from the toilet.
k. Valve blade / valve seal.
l. Vent plunger: for emptying the waste tank without
splashing.
m. Handle.
n. Valve blade opener.
o. Access door.
C-200 CW / CWE PARTS
AND FUNCTIONS
a. Removable seat and cover
b. Swivelling toilet bowl.
c. Valve blade handle.
d. Flush water tank.
e. Level indicator: warning light illuminates when the
waste tank requires emptying.
f. Flush lever: the toilet flushes when the lever is moved
up and down.
g. Power supply for the level indicator:
two Penlite/AA 1.5 V alkaline batteries.
h. Waterfill door.
i. Rotating emptying spout: ensures that the waste tank
can be easily and hygienically emptied.
j+k. Automatic pressure release vent: ventilates the waste
tank when this is inserted into the cassette toilet.
Avoids excessive pressure build up in the waste tank.
N.B. A black hose is attached to the automatic pressure
release vent on some toilets. This hose transports the
air to the outside through a hatch or through the floor.
l. Upper handle.
m. Cover: guarantees optimal hygiene. Opens when the
waste tank is inserted into the toilet and closes when
the waste tank is removed from the toilet.
n. Valve blade / valve seal.
o. Vent plunger: for emptying the waste tank without
splashing.
p. Handle.
q. Valve blade opener
r. Access door.
INTRODUCTION
The toilet is made up of two parts: a permanently fixed
toilet and a waste tank that is accessible from the outside.
The removable waste tank is located under the toilet and
can be removed via an access door on the outside of the
caravan or motor home.
PREPARING FOR USE
1. Remove the waste tank by pulling the safety catch
upwards.
2. Pull the waste tank outwards to the stop. Tip it slightly
and take out the tank completely.
3. Place the tank upright and turn the emptying spout
upwards.
4. Remove the cap, with the measuring cup inside, from
the emptying spout and pour the stated quantity of
Thetford toilet fluid into the waste tank. This quickly
breaks down waste, avoids unpleasant smells in the
waste tank and keeps the inside of the waste tank
clean. Add approximately 2 litres of water - enough to
ensure that the bottom of the waste tank is covered.
Screw the measuring cap back onto the emptying
spout. Turn the emptying spout back to its original
position.
Warning! Never add toilet fluid via the valve blade or
via the toilet bowl.
5. Slide the waste tank back into its original position via
the access door.
Note! Never use force if you are having trouble getting
the tank back into place easily. This may cause serious
damage.
6. Make sure that the waste tank is secured with the
safety catch. Shut the access door and lock it.
Point 7 only applies to models CW / CWE.
CW / CWE
7. Open the water fill door and fill the flush tank with the
stated amount of Thetford Aqua Rinse. This keeps the
flush water fresh and improves the flushing. Next, fill
the flush water tank with clean water using a jerry can
or hose.
USE
8. Turn the toilet bowl to the desired position.
