SINGER 14T967DC QUANTUMLOCK - Manual (Page 7)

Stitch Type Reference
Page
8. Four-thread
Safety Stitch made up of combined 2-thread
overedge and double chainstitch.
47
9. Five-thread The 5-thread stitch is a safety stitch
Safety Stitch made up of combined 3-thread
Wide overlock and double chainstitch.
48
A wide seam is formed by using left needle.
Overedge and seaming can be done
in one operation on non-stretch fabrics.
10. Five-thread The 5-thread stitch is a safety stitch
Safety Stitch made up of combined 3-thread
Narrow overlock and double chainstitch. 48
11. Cover Stitch 2-needle, 3-thread cover stitch is
Narrow suitable for stretchy fabrics such as
(2.8mm) knits, etc. 51
A narrow seam is formed by using left
and middle needles.
12. Cover Stitch 2-needle 3-thread cover stitch is
Wide suitable for stretchy fabrics such as
(5.6mm) knits, etc.
51
A wide seam is formed by using left
and right needles.
13. Triple Cover 3-needle 4-thread cover stitch is
Stitch suitable for stretchy fabrics such as
(5.6mm) knits, etc.
52
A triple seam is formed by using left,
middle, and right needles.
14. Three-thread 1-needle 3-thread stitch is used for sewing
Rolled Hem narrow rolled hems.
55
A narrow seam is formed by using right
Needle. Overege and seaming can be done
in one operation on non-stretch fabrics.
The 4-thread stitch is a safety stitch
ATD : Auto Tension Dial Selected
ATD: I
ATD: B
ATD: A
ATD: K
ATD: H
ATD: J
ATD: C
6
