SINGER 14T967DC QUANTUMLOCK User Manual
Page 11
2
1
3
4
5
6
7
8
10
9
11
12
13
14
15
17
16
18
5. PRINCIPAL PARTS
1. Thread guides and holder
2. Handle
8. Needle plate
9. Cloth plate
10. Looper cover
11. Power & light switch
12. Stitch length dial
13. Hand wheel
14. Spool stand
15. Cone adaptor
16. Spool pin
17. Waste tray
10
1 . Auto tension dial
8
3. Left needle thread tension fine tuning lever (orange)
4. Right needle thread tension fine tuning lever (blue)
5. Upper looper thread tension fine tuning lever (green)
6. Lower looper thread tension fine tuning lever (red)
7. Chain stitch looper thread tension fine tuning lever (brown)
