SINGER 14T967DC QUANTUMLOCK - Manual (Page 45)

Needle thread
Upper looper thread
Needle thread
Upper looper thread
Topside
Underside
Lower looper thread
Topside
Underside
Needle thread
Lower looper thread
Needle thread
Fabric
Medium weight
Needle thread
Topside
Upper looper thread
Lower looper thread
Needle thread
Underside
Green
Tension Dial
Orange Blue Red Brown
STITCH LENGTH
Upper looper thread
Needle thread
SEAM WIDTH FINGER KNOB
Topside
Needle thread
Lower looper thread
Underside
2~4
N
N/A
Medium weight
Fabric
Tension Dial
Green Orange Blue Red Brown
NEEDLE POSITION
44
How to Balance
Set auto tension dial to F shown at right
and test sew on a sample of your fabric.
5) 3-thread Flatlock
Correct Balance
When the lower looper thread tension is too loose;
-Move the lower looper thread tension
lever (red) fine tuning
toward position a higher .
- Or, the needle thread tension (orange move fine tuning lever
or blue) position toward a lower .
When the upper looper thread tension is too loose;
-
the upper looper thread tension Move fine tuning lever
(green) position toward a higher .
- Or, the needle thread tension (orange move fine tuning lever
or blue) position toward a lower .
When the needle thread tension is too loose;
-
the needle thread tension (orange Move fine tuning lever
or blue) position toward a higher .
-Or, the upper looper thread tension move fine tuning lever
(green) position toward a lower .
SPREADER
ATD:F
Tension is automatically set when seiecting the
desired stitch type with the Auto Tension Dial (ATD).
Tension may be fine tuned with the Fine Tuning Levers
according to the following variables
1) Type and thickness of fabric
2) Needle size
3) Size, type and fibre content of thread
:
