Note
D300 Series Wireless Wheelchair Scale Installation & Operation Manual — Using the Scale 7
Once the handheld controller is turned off, the chair weight is gone.
5. Attach mini ramps back onto the scale pads.
6. Remove wheelchair off of scale pads.
Enter Chair Weight
To manually enter a chair weight, press the down arrow to highlight
Enter Chair Weight
.
1. Prior to manually entering the wheelchair weight, place the included wheel stops and mini ramps onto the
scale pad as shown in Figure 4-1.
2. Roll the wheelchair backwards onto the center of each pad.
3. Set the brakes on the wheelchair and remove mini ramps prior to weighing.
4. Press
OK
.
5. Press the up arrow or the down arrow to begin the numbers scrolling in 5 lb increments (press and hold for
faster scrolling) until you get to the chairs’ correct weight and press
OK
. The controller should read
Is This
Correct? Yes
should be highlighted and if the weight is correct, press
OK
. If the weight is not correct, press
the down arrow to highlight
NO
and press
OK
. Repeat until correct.
6. Attach mini ramps back onto the scale pads.
7. Remove wheelchair off of scale pads.
4.2.2 Patient + Chair
Use the down arrow to the highlighted
Patient + Chair
. Use the following steps to find the weight of the patient and
the chair.
1. Place each scale pad on a solid, flat surface (tile, cement, hardwood).
2. Place the wheel stops on the scale pads.
3. Press the down arrow key and scroll down until
Zero Out Pads
is highlighted and press
OK
.
4.
Check and remove anything from the scale pads
is displayed. Press
continue
to initiate the zero out function.
(when the controller is in process the screen will go dim for approximately five seconds and while the
controller is zeroing out each pad, the scale pads will illuminate green.
Important
If any of the four pad indicator lights are red or yellow in color, or if the controller indicates
COMM ERROR, TRY AGAIN
, press the up arrow to highlight the
Yes
prompt. Press
OK
and repeat the
zeroing out process.
5. After the controller completes the process, the display shows
Zeroing Complete
and will verify that all four
pad numbers on the controller display are indicated with green circles.
6. The controller will ask
Repeat Zero Out.
If all numbers are circled in green in the controller display, then
highlight
NO
and then press
OK
and return back to the main menu screen.
7. Place mini ramps in front of each scale pad making sure the scale pads are placed behind the wheelchair.
8. Roll the wheelchair onto the scale pads, as close to the center of the pad as possible and ensure brakes are
on.
9. Assist patient into the chair.
10. Remove mini ramps prior to weighing the patient.
11. Press
Patient + Chair
and the display will show
Weighing
. During this time the display screen will dim for
approximately five seconds and the scale pads will be lit green. Patient weight will then be displayed. The
display
Save?
is shown. Press
Yes
to save that weight and will be saved until the next use. If the user does
not wish to save the weight, press the down arrow to highlight
NO
and then press
OK
to return back to the
main menu.
12. Attach mini ramps back onto scale pads.
13. Remove wheelchair and patient off of scale pads.
