4 12 VDC Remote Power Supply Installation Instructions
Specifications
Enclosure Fiberglass, NEMA 4X
8 in x 6 in x 4 in
Input voltage: 90–265 VAC
DC voltage: 12 V
Rated current: 3.7A
Current range: 0–4.4A
Rated power: 44.4W
Voltage adjustment range: 11.4–13.2 V
Line regulation:
± 1.0%
Operating temperature: –10°C to +60°C (14°F to 140°F)
Working humidity: 20% to 90% RH, non-condensing
Storage temperature: –20°C to +85°C (–4°F to 185°F)
Storage humidity: 10% to 95% RH
Ref Number PN Description (Quantity) See Figure
1 110496 Enclosure (1) 2
2 78950 Power cord assembly (1), includes cord grip, seal ring, lock nut, and reducing
gland for AC power cable
3 15628 Cord grip, 1/2 NPT (1)
4 30376 Seal ring, 1/2 NPT (1)
5 15630 Lock nut, 1/2 NPT (1)
6 80589 Cable tie mounts (2)
7 110497 Back panel (1)
8 109526 Machine screws, 10-32NC x 3/8 (4)
9 109529 Machine screw, 8-32NC x 3/8 (1)
10 110580 6-position, 2-wire MTA cable (1) 3
11 15631 Cable ties (2) 2
12 72996 12V power supply board (1)
— 54224 Replacement power supply fuse (1)
13 109396 Transient protection board (1)
14 14825 Machine screws, 4-40NC x 1/4 (8)
16 88733 Breather vent (1) 3
17 16861 High voltage warning label (1)
18 88734 Breather vent nut (1) 2
19 16892 Earth/ground label (1)
— 15665 Reducing gland for output power cord grip, 1/2 NPT (1), included in parts kit —
Table 1. Replacement Parts
