PT300 Users Manual
Rev E, April 1999
Page 3 of 21
Introduction
This manual contains specifications and operating instructions for the PT300 system.
Specifications
Controls
General: On, Off, Print, lb/kg, Test/Zero, Local/Total, Hold/Rel, Lamp
Display: 0.5” 6 digit, LCD
Electrical
Voltage: 12 VAC,VDC
Batteries: 6 “AA” size alkaline or rechargeable ni-cad batteries
Fuse: Type #1AG1A (little)
Performance
Accuracy:
±
1.0% of applied load or
±
1 display graduation, whichever is greater.
Divisions: 20,000 lb / 9350 kg: Graduation = 50 lb / 25 kg
Speed:
≈
1 sec to typical reading (static)
Environmental
Temperature: Operating: -20
°
F to 150
°
F / -28
°
C to 65
°
C
Storage: -40
°
F to 170
°
F / -40
°
C to 75
°
C
Humidity: 10 – 95% non-condensing
Physical
Dimensions (PT300): Overall: 3 x 16 x 20 in. / 76 x 406 x 508 mm
Pad: 12 x 12 in. / 305 x 305 mm
Weight (PT300): 37 lb / 16.8 kg
Dimensions (PT300DW): Overall: 3 x 26 x 20 in. / 76 x 660 x 508 mm
Pad: 22 x 14 in. / 559 x 356 mm
Weight (PT300DW): 49 lb / 22 kg
