Mounting Kits PR 6011 Installation Manual
EN-4 Sartorius
3 Technical Data
3.1 MiniFLEXLOCK PR 6011/30
PR 6011/30N PR 6011/30S
Load cell max. capacity 500 kg…10 t
Permissible temperature range -40 °C…+80 °C
Permissible horizontal force 5 kN
Perm. lifting force see Chapter 6
Mounting bolts
Thread size M8
Rigidity class 5.8 A2
Weight
net 5.00 kg 5.20 kg
with packing 5.35 kg 5.90 kg
Material Steel, zinc-plated, chromated
and sealed (in compliance with
RoHS directive)
stainless steel 1.4301 acc. to
DIN EN 10088-3
Mounting aid all dimensions in mm
Caution!
Remove the mounting aid after mounting!
