Packing the arm for transit
Th e dual pivot bearing is a very precise and in
some ways delicate mechanism. Every care has
been taken to ensure that the arm reaches you in
perfect condition such that the bearings are accurate
and very low in friction. If you need to send the
arm anywhere for various reasons the following
proceedure must be followed carefully.
Remove the counterweight and wind the vta
adjuster wheel up as high as possible.
Unwind the Azimuth adjustment screws by 4
Unwind the Azimuth adjustment screws by 4
turns exactly turns exactly
Tighten the azimuth clamping screws lightly onto
the azimuth adjustment screws to ensure that they
don’t move in transit.
Insert the two cork peices into the top of the yoke
as shown in the photo. NOTE - the cork strips are
tapered and will only fi t in with the narrow end
fi rst. Th ese strips are not absolutely essential but do
act as a safeguard against the arm being forced out
of parrallel with the base of the yoke.
Tightly tape the arm tube to the arm rest plate
- cellotape or masking tape is fi ne.
Place the arm in it’s aluminium fl ight case and then
enclose this in a card box to ensure that it does not
open in transit.
