320
Controls in detail
Useful features
Removing ashtray insert
̈ Grip ashtray insert 2 on the sides and
pull it out upwards.
Reinstalling ashtray insert
̈ Insert ashtray insert 2 and push down
until the ball catch engages.
̈ Close ashtray cover plate 1.
Rear seat ashtray (second row)
Opening the ashtray
1 Ashtray cover
2 Ashtray insert
̈ Open ashtray cover 1 ( ୴ page 312).
̈ Press ashtray cover 1 down in
direction of arrow as far as it will go.
Removing ashtray insert
̈ Open ashtray cover 1.
̈ Press ashtray cover 1 down in
direction of arrow as far as it will go.
1 Ashtray cover
2 Ashtray insert
̈ Push on ashtray insert 2 and pull it
out upwards.
Reinstalling ashtray insert
̈ Insert ashtray insert 2 into opening.
̈ Push down ashtray insert 2 until it
engages.
̈ Close ashtray cover 1.
Warning!
G
Remove ashtray insert only with vehicle
standing still. Set the parking brake to
secure vehicle from movement. Set auto-
matic transmission to P. With the automatic
transmission set to P, turn off the engine.
i Vehicles with rear center console*
( ୴ page 323) are not equipped with an ashtray
in front of the second-row seats.
!
Close the ashtray when not in use and be-
fore folding the second-row seats.
