Climate control system
195
X
Opening the center air vents: Turn
thumbwheels
2
and
5
upward to the first
stop.
Center air vents
1
,
3
,
4
and
6
are
open.
X
Turn thumbwheels
2
and
5
upward all
the way.
Only center air vents
3
and
4
are open.
X
Closing the center air vents: Turn thumb-
wheels
2
and
5
downward all the way.
Center air vents
1
,
3
,
4
and
6
are
closed.
Side air vents
Example illustration driver’s side
1
Left side defroster air vent, fixed
2
Left side air vent, adjustable
3
Thumbwheel for air volume control for
adjustable left side air vent
X
Opening/closing: Turn thumbwheel
3
in
the required direction.
AIRSCARF vent
When switching on the AIRSCARF neck-
level heating, the air streaming from the
openings may be very hot. When in close
proximity to the openings, you could be
seriously burned. To help avoid serious per-
sonal injuries, switch the AIRSCARF to a
lower heating level.
1
AIRSCARF vent
You can switch on the AIRSCARF neck-level
heating with the AIRSCARF switch
(
The symbols on the control represent the fol-
lowing functions:
Symbol
Function
Z
Directs air to the windshield and
through the side defroster air
vents
b
Directs air into the entire vehi-
cle interior
Y
Directs air to the footwells and
through the side air vents
a
Directs air through the center
and side air vents
Climate control
The air distribution can be adjusted manually.
Controls in detail
Z
