Instrument cluster
31
Function Page
1 Combination gauge with:
Fuel gauge
4 Fuel tank reserve
warning lamp
344
Coolant temperature gauge
Ì Coolant temperature
warning lamp
346
Indicator/warning lamps:
A High-beam headlamp
indicator lamp
102
B Low-beam headlamp
indicator lamp
100
± Engine malfunction
indicator lamp
345
; Brake warning lamp,
USA only
339
3 Brake warning lamp,
Canada only
339
2 L Left turn signal
indicator lamp
103
Function Page
3 v ESP ® warning lamp 343
4 Speedometer
5 Multifunction display 133
6 K Right turn signal
indicator lamp
103
7 Tachometer with:
¯ ESP OFF warning
lamp, C 63 AMG only 70,
343
H Combination low tire
pressure/TPMS
malfunction telltale, USA
only
270,
347
= Supplemental
Restraint System (SRS)
indicator lamp
43,
342
- Antilock Brake
System (ABS) indicator
lamp
337
Function Page
< Seat belt telltale 56,
340
8 Outside temperature
(manual transmission)
130
Outside temperature/
additional speedometer
(automatic transmission)
130,
147
9 Outside temperature
(automatic transmission) 130,
147
a Program mode indicator
(automatic transmission)
124
b Transmission position
indicator/ gear range
indicator
(automatic transmission)
122,
124
Additional speedometer
(manual transmission)
146
c Digital clock 147
d Instrument cluster
illumination
129
At a glance
