Page 150
X
Make sure that wiper blade : is seated
correctly.
X
Fold the wiper arm back onto the
windshield.
Replacing the wiper blades (MAGIC
VISION CONTROL)
Moving the wiper blades to a vertical
position
X
Turn the SmartKey to position 0 in the
ignition lock (
Y
page 171).
X
Set the windshield wiper to the °
position.
X
Turn the SmartKey to position 1 in the
ignition lock (
Y
page 171).
X
As soon as the wiper arms are vertical to
the hood, turn the SmartKey to position 0
in the ignition lock (
Y
page 171).
X
Remove the SmartKey.
X
Fold the wiper arms away from the
windshield until you feel them snap into
place.
Removing a wiper blade
X
To bring the wiper blade into position
to be removed: hold the wiper arm firmly
with one hand. With the other hand, turn
the wiper blade in the direction of
arrow : beyond the point of resistance.
The wiper blade engages in the removal
position with an audible click.
X
To remove a wiper blade: firmly press
release knob ; and pull the wiper blade
upwards =.
Installing the wiper blades
X
Push the new wiper blade in the direction
of arrow : onto the wiper arm until
tab ; engages.
X
Push the wiper blade out of the removal
position in the direction of arrow = beyond
the point of resistance.
The wiper blade disengages with an audible
click and is freely movable again.
X
Make sure that the wiper blade is seated
correctly.
X
Fold the wiper arm back onto the
windshield.
