Quick Reference Guide
Initial Factory Settings
Quick Reference Guide
Initial Factory Settings
2.7 in (68mm)
Steering
2.8 in (70.8mm)
Back Axles = Left Side
Silver Axles = Right Side
Two Speed - 5 turns out Slipper - 1 turn out
Engine
Rear Toe-In
x1
x5
x 2 3 /
4
x 3
Low-Speed Needle - 3 turns out High-Speed Needle - 2 3 /
4
turns out
Using Nitrotane 20% Sport Fuel Using Nitrotane 20% Sport Fuel
Losi 30 wt
Shock Oil
(LOSA5224)
Axles & Nuts
Shocks Tie Rods
Transmission
Troubleshooting Chart Troubleshooting Chart
Problem Things to Check Remedy
Engine won't start.................................. Out of fuel
Spoiled or improper fuel
Glow plug not lighting
Glow igniter battery low
Engine overheated
Engine flooded
Air cleaner blocked
Exhaust blocked
Check/replace glow plug
Charge/change battery
Let cool - see "Testing the Temperature”
Clean and reoil aircleaner
Engine won't turn over......................... Engine is flooded
Engine seized Loosen glow plug and try again
Damaged, if will not turn over
Engine starts, then stalls....................... Idle speed set too low
Glow plug is fouled/weak
Air bubbles in fuel line
Engine is overheated
Insufficient fuel tank pressure/blockage See "Carburetor Adjustments"
See "About Glow Plugs"
Check for split/hole in fuel line
See "Testing the Temperature"
Clear pressure line
Engine performing poorly.................. High-speed fuel mixture is too rich
Engine overheating
Leaking glow plug
Carburetor dirty or blocked
Fuel bad or contaminated
Clutch or slipper slipping
Bound up drivetrain
Engine worn out See "Engine Tuning"
See "Engine Tuning" Richen 2 hours
Replace glow plug
Try fresh fuel
Clean/Adjust/Repair
Check for binds in drivetrain
Rebuild
Engine overheats................................... High-speed fuel mixture is too lean
Low-speed fuel mixture too lean
Spoiled or improper fuel
Cooling air is being blocked
Excessive load on the engine See "Understanding Rich and Lean”
Clean head fins
Check for binds/dirt build up
Engine hesitates or stumbles............. Engine overheated
High-speed mixture too lean
Low-speed mixture too rich
Air bubbles in fuel line
Glow plug fouled See "Engine Tuning," Richen 2 hours
See "Engine Tuning," Richen 2 hours
See "Engine Tuning," Richen 1 hour
Check fuel line for holes
Change glow plug
Engine stalls instantly when throttle
is fully opened from idle......................
Glow plug fouled
High-speed mixture too rich
Low-speed mixture too lean Change glow plug
See "Engine Tuning"
See "Engine Tuning," Richen 1 hour
Engine stalls while driving around
turns....................................................
Fuel level is low
Idle speed set too low Add Fuel
Increase idle speed
Engine stalls while idling..................... Low-speed mixture too rich
Low-speed mixture too lean
Idle speed too low
Clutch shoes dragging
Clutch bearings failed
Engine worn out
See "Engine Tuning"
See "Engine Tuning"
Increase idle speed
Check for broken clutch springs
Check/Clean/Replace
Rebuild
