COMe-cDC2 / Features and Interfaces
4.10.2 Storage
Device Function
EEPROM 0 JIDA EEPROM Area1 with 32 Bytes (free to use)
4.10.3 GPIO
Port Function
IO-Port 0 GPI0 Port
Bit 0-3: Input
Bit 4-7: Output
4.10.4 Onboard Hardware Monitor
Sensor Function
Temp 0 CPU Temperature (measured with ADT7475 HWM)
Temp 1 Board Temperature (internal IC temperature of onboard ADT7475 HWM)
Temp 2 Chipset Temperature
FAN 0 Onboard CPU FAN
Voltage 0 Module RTC Battery input
Voltage 1 Module 3.3V S0 voltage
4.10.5 SIO Winbond 83627DHGP
Sensor is only available if external carrier board SIO Windbond/Nuvoton 83627DHGP is present
Sensor Function
Temp 3 Temp Sensor 1 (SYSTIN)
Temp 4 Temp Sensor 2 (CPUTIN)
Temp 5 Temp Sensor 3 (AUXTIN)
FAN 1 FAN Sensor 0 (SYSFANIN)
FAN 2 FAN Sensor 1 (CPUFANIN0)
FAN 3 FAN Sensor 2 (AUXFANIN0)
FAN 4 FAN Sensor 3 (SYSFANIN1)
Voltage 2 Voltage Sensor 0: VCore
Voltage 3 Voltage Sensor 1: VIN0
Voltage 4 Voltage Sensor 2: AVCC
Voltage 5 Voltage Sensor 3: 3VCC
Voltage 6 Voltage Sensor 4: VIN1
Voltage 7 Voltage Sensor 5: VIN2
Voltage 8 Voltage Sensor 6: VIN3
Voltage 9 Voltage Sensor 7: 3VSB
Voltage 10 Voltage Sensor 8: VBAT
