5.2.14 SLOT 2 Sideband Connector J24
Table 12: SLOT 2 Sideband Connector J24 Pinout
COMMENT
COM EXPRESS
CONNECTION
SIGNAL
PIN ROW
SIGNAL
COM EXPRESS
CONNECTION
COMMENT
B A
Not connected NC 1 1 NC Not connected
Not connected NC 2 2 NC Not connected
Not connected NC 3 3 NC Not connected
Ground GND 4 4 GND Ground
Not connected NC 5 5 SLOT2_I2C_ADDR1 Slot2 I2C address
coding: NC
Not connected NC 6 6 SLOT2_I2C_ADDR2 Slot2 I2C address
coding: 1k PD to
GND
Ground GND 7 7 SLOT2_DEV_ADDR0 Slot2 DEV address
coding: 1k PD to
GND
Not connected NC 8 8 SLOT2_DEV_ADDR1 Slot2 DEV address
coding: NC
Slot2 I2C address
coding: NC SLOT2_I2C_ADDR0 9 9 NC Not connected
Not connected NC 10 10 NC Not connected
USB overcurrent
status signal to
COME module USB_0_1_OC# USB_P0_1_OC# 11 11 WLAN_DISABLE# WLAN disable out-
put from glue logic
GPIO from/to car-
rier glue logic SLOT2_GPIO 12 12 GND Ground
Ground GND 13 13 NC Not connected
USB differential
pair from/to COME
module USB1+ USB_P[1]+ 14 14 NC Not connected
USB1- USB_P[1]- 15 15 GND Ground
Ground GND 16 16 NC Not connected
EXCD0_CPPE# sig-
nal to COME mod-
ule, PRSNT# card
detect signal to
carrier glue logic,
8k2 PU on carrier
to V_3V3_STDBY EXCD1_CPPE# EXCD1_CPPE# 17 17 NC Not connected
Ground GND 18 18 GND Ground
