Quick Start Guide
COME-QEC-1
Table 3: Connector J2 Rows C and D Pinout
COMMENT SIGNAL PIN PIN SIGNAL COMMENT
GND C1 D1 GND
for use with COMe-bP2020 GBE1_ACT# C2 D2 GBE2_ACT# for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI3- C3 D3 GBE2_MDI3- for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI3+ C4 D4 GBE2_MDI3+ for use with COMe-bP2020
for use with COMe-bP2020 GBE1_LINK100# C5 D5 GBE2_LINK100# for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI2- C6 D6 GBE2_MDI2- for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI2+ C7 D7 GBE2_MDI2+ for use with COMe-bP2020
for use with COMe-bP2020 GBE1_LINK1000# C8 D8 GBE2_LINK1000# for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI1- C9 D9 GBE2_MDI1- for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI1+ C10 D10 GBE2_MDI1+ for use with COMe-bP2020
GND C11 D11 GND
for use with COMe-bP2020 GBE1_MDI0- C12 D12 GBE2_MDI0- for use with COMe-bP2020
for use with COMe-bP2020 GBE1_MDI0+ C13 D13 GBE2_MDI0+ for use with COMe-bP2020
for use with COMe-bP2020 GBE1_LINK# C14 D14 GBE2_LINK# for use with COMe-bP2020
NC C15 D15 NC
NC C16 D16 NC
accessible via J22 LOE# C17 D17 LCS0# accessible via J22
accessible via J22 LWE[0]# C18 D18 LCS1# accessible via J22
accessible via J18 SERDES_RX6+ C19 D19 SERDES_TX6+ accessible via J18
accessible via J18 SERDES_RX6- C20 D20 SERDES_TX6- accessible via J18
GND C21 D21 GND
accessible via J18 SERDES_RX7+ C22 D22 SERDES_TX7+ accessible via J18
accessible via J18 SERDES_RX7- C23 D23 SERDES_TX7- accessible via J18
N/C C24 D24 LA31 accessible via J22
N/C C25 D25 LA30 accessible via J22
N/C C26 D26 N/C
accessible via J22 LAD0 C27 D27 N/C
accessible via J22 LAD1 C28 D28 GND
N/C C29 D29 N/C
N/C C30 D30 N/C
GND C31 D31 GND
accessible via J22 LAD2 C32 D32 N/C
accessible via J22 LAD3 C33 D33 N/C
accessible via J22 LAD4 C34 D34 N/C
accessible via J22 LAD5 C35 D35 LALE accessible via J22
accessible via J22 LAD6 C36 D36 N/C
accessible via J22 LAD7 C37 D37 N/C
accessible via J22 LAD8 / GPIO0 C38 D38 GND
accessible via J22 LAD9 / GPIO1 C39 D39 SER0_CTS#
accessible via J22 LAD10 / GPIO2 C40 D40 SER0_RTS#
GND C41 D41 GND
accessible via J22 LAD11 / GPIO3 C42 D42 SER1_CTS#
accessible via J22 LAD12 / GPIO4 C43 D43 SER1_RTS#
accessible via J22 LAD13 / GPIO5 C44 D44 LBCTL accessible via J22
accessible via J22 LAD14 / GPIO6 C45 D45 LGTA# accessible via J22
accessible via J22 LAD15 / GPIO7 C46 D46 IRQ3# / GPIO connected to carrier logic (not
actually used) and J25
