AM5010 IPMI Firmware User Guide
ID 1022-2948, Rev. 1.0 © 2008 Kontron AG Page 17
6.2.2 OEM Commands and Extensions
6.2.2.1 Get Device ID Command with OEM Extensions
LUN NetFn CMD
Get Device ID command with OEM extensions 00h App = 06h 01h
Byte Data Field
Request Data - -
1 Completion Code
2:12 Regular Get Device ID Command response fields
13 Release index (e.g. 101 denotes release index 1.01)
Please note: Some tools offer this as “SDR version”.
14 Module Geographical Address (site number):
1 … 8 = Module in AMC bay A1, A2 ,A3, A4, B1, B2, B3, B4
or in µTCA slot 1 … 8 with bus addresses
72h, 74h, 76h, 78h, 7ah, 7ch, 7eh, 80h
9 …12 = Module in µTCA slot 9 … 12 = Bay C1, C2, C3, C4
with bus addresses 82h, 84h, 86h,88h
0, > 12 = Module position is not in range. The IPMB-L bus is
switched off (ref. to 6.3).
15 Reserved
Response Data
16 Reserved
