6.6.5 Advanced settings – Hardware Health Configuration
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration Disable = Full Speed
Thermal: Does regulate
fan speed according to
specified temperature
Speed: Does regulate
according to specified
RPM
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
System Temperature :48ºC/118ºF
CPU Temperature :56ºC/132ºF
VTIN Temperature :N/A
SYS FAN Speed :Fail
Fan Cruise Control [Disable]
Fan Type [4 Wire]
CPU FAN Speed :2537 RPM
Fan Cruise Control [Thermal]
Fan Setting [45°C/113°F]
Fan Type [4 Wire]
AUXFAN Speed :2164
Fan Cruise Control [Speed]
Fan Setting [2177 RPM]
Fan Step Time [2]
Low RPM Fan Range [Disabled]
Watchdog Function [Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Feature Options Description
Fan Cruise Control Disabled
Thermal
Speed
Select how the Fan shall operate.
When set to Thermal, the Fan will start to run at the
CPU die temperature set below.
When set to Speed, the Fan will run at the fixed
speed set below.
Fan Settings 1406-5625 RPM
30°-60°C
The fan can operate in Thermal mode or in a fixed
fan speed mode
Fan Type 4 wire
3 wire
Select the electrical interface for the fan:
3 Wire = PWM output to fan power line. RPM reading
and speed regulation at lower speed might be poor.
4 Wire = 12VDC always PWM on control signal
Fan Step Time 0, 1, 2, 3, 4, 5, 6, 7 Fan regulation delay. (0 is fast and 7 is slow)
Low RPM Fan Range Disabled
Enabled
Enabled: Down to 500 RPM is possible. Note that if
Speed setting is used then set the speed to the
double of the requested RPM.
Watchdog Disabled
15 seconds
30 seconds
1 minute
2 minutes
5 minutes
10 minutes
To be serviced via API.
Note: The AUXFAN is available via Feature Connector.
