3.4 Display connector
The KTQ45 board family provides onboard Analogue CRT interface. Additionally the KTQ45 boards provides
support for ADD2 cards through the onboard PCI Express x16 connector, with extension capability for
support of DVI, LVDS, VGA, HDMI/UDI, TV-Out, etc.
If a PCI Express x16 Graphics add-in card is used, the onboard Graphics controller (GMA 4500) is disabled.
3.4.1 CRT Connector (CRT)
Note Pull
U/D
Ioh/Iol Type Signal PIN Signal Type Ioh/Iol Pull
U/D
Note
6 GND PWR - -
/75R * A0 RED 1 11 NC - - -
7 GND PWR - -
/75R * A0 GREEN 2 12 DDCDAT IO TBD 2K2
8 GND PWR - -
/75R * A0 BLUE 3 13 HSYNC O TBD
9 5V PWR - - 1
- - - NC 4 14 VSYNC O TBD
10 GND PWR - -
- - PWR GND 5 15 DDCCLK IO TBD 2K2
Signal Description - CRT Connector:
Pin Signal Description
1 RED Analogue output carrying the red colour signal to the CRT. For 75 Ohm cable impedance.
2 GREEN Analogue output carrying the green colour signal to the CRT. For 75 Ohm cable impedance.
3 BLUE Analogue output carrying the blue colour signal to the CRT. For 75 Ohm cable impedance.
4 NC No Connection
5-8 GND
9 5V This 5V supply is fused by a 1.1A resettable fuse.
10 GND
11 NC No Connection
12 DDCDAT Display Data Channel Data. Used as data signal to/from monitors with DDC interface.
13 HSYNC CRT horizontal synchronization output.
14 VSYNC CRT vertical synchronization output.
15 DDCCLK Display Data Channel Clock. Used as clock signal to/from monitors with DDC interface.
