KTD-00782-I KTQ45 family Page 58 of 92
BIOS Configuration/Setup
6.4 Introduction
The BIOS Setup is used to view and configure BIOS settings for the KTQ45 board. The BIOS Setup is
accessed by pressing the DEL key after the Power-On Self-Test (POST) memory test begins and before the
operating system boot begins. The Menu bar looks like this:
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
The available keys for the Menu screens are:
Select Menu: <←> or <→>
Select Item: <↑> or <↓>
Select Field:
Change Field: <+> or <->
Help:
Save and Exit:
Exits the Menu:
Please note that in the following the different BIOS Features will be described as having some options.
These options will be selected automatically when loading either Failsafe Defaults or Optimal Defaults. The
Default options will be indicated by the option in bold, but please notice that when Failsafe Defaults are
loaded a few of the options, marked with “*”, are now the default option.
6.5 Main Menu
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
System Overview Use [ENTER], [TAB] or
[SHIFT-TAB] to select a
field.
Use [+] or [-] to
configure system Time.
<-> Select Screen
|| Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
AMIBIOS
Version : 08.00.15
Build Date: 10/30/12
ID : KTQ45015
PCB ID : B1
Serial # : 00793263
Part # : 62210000
Processor
Intel® Core™ 2 CPU Q9600 @ 3.0GHz
Speed : 3000MHz
System Memory
Size : 3294MB
System Time [16:33:13]
System Date [Thu 10/31/2013]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Feature Options Description
System Time HH:MM:SS Set the system time.
System Date MM/DD/YYYY Set the system date.
