Kontron KTQ45-FLEX - Manual (Page 32)

KTD-00782-I KTQ45 family Page 32 of 92
GND B29 A29 PCIE_RXP[4]
NC B30 A30 PCIE_RXN[4]
NC B31 A31 GND
GND B32 A32 NC
NC B33 A33 NC
NC B34 A34 GND
GND B35 A35 NC
GND B36 A36 NC
NC B37 A37 GND
NC B38 A38 GND
GND B39 A39 NC
GND B40 A40 NC
NC B41 A41 GND
NC B42 A42 GND
GND B43 A43 NC
GND B44 A44 NC
NC B45 A45 GND
NC B46 A46 GND
GND B47 A47 NC
NC B48 A48 NC
GND B49 A49 GND
NC B50 A50 NC
NC B51 A51 GND
GND B52 A52 NC
GND B53 A53 NC
NC B54 A54 GND
NC B55 A55 GND
GND B56 A56 NC
GND B57 A57 NC
NC B58 A58 GND
NC B59 A59 GND
GND B60 A60 NC
GND B61 A61 NC
NC B62 A62 GND
NC B63 A63 GND
GND B64 A64 NC
GND B65 A65 NC
NC B66 A66 GND
NC B67 A67 GND
GND B68 A68 NC
GND B69 A69 NC
NC B70 A70 GND
NC B71 A71 GND
GND B72 A72 NC
GND B73 A73 NC
NC B74 A74 GND
NC B75 A75 GND
GND B76 A76 NC
GND B77 A77 NC
NC B78 A78 GND
NC B79 A79 GND
GND B80 A80 NC
NC B81 A81 NC
NC B82 A82 GND
