3.5 PCI-Express connectors
The KTQ45 board supports one 16-lane (x16) PCI Express port and one 4-lane PCI Express (x16) port.
The 16-lane (x16) PCI Express 2.0 port can be used for external PCI Express graphics card. It is located
nearest the CPU.
Supports PCI Express GEN1 frequency of 1.25 GHz (supports 2.5 Gbit/s in each direction, 500 MB/s totally).
Maximum theoretical bandwidth using 16 lanes is 8 GB/s.
Supports PCI Express GEN2 frequency of 2.5 GHz (supports 5.0 Gbit/s in each direction, 1000 MB/s totally).
Maximum theoretical bandwidth using 16 lanes is 16 GB/s.
The PCI Express (x16) interface is multiplexed with the SDVO ports.
The 4-lane (x4) PCI Express 1.1 port is mechanically a x16 port and electrically a x4 port. It is located
farthest away from CPU.
3.5.1 PCI-Express x16/SDVO Connector (PCIe x16/SDVO)
Note Type Signal PIN Signal Type Note
+12V B1 A1 NC
+12V B2 A2 +12V
+12V B3 A3 +12V
GND B4 A4 GND
SMB_CLK B5 A5 NC
SMB_DATA B6 A6 NC
GND B7 A7 NC
+3V3 B8 A8 NC
NC B9 A9 +3V3
SB3V3 B10 A10 +3V3
WAKE# B11 A11 RST#
NC B12 A12 GND
GND B13 A13 PCIE_x16 CLK
PEG_TXP[15]/SDVOB_RED B14 A14 PCIE_x16 CLK#
PEG_TXN[15]/SDVOB_RED# B15 A15 GND
GND B16 A16 PEG_RXP[15]/SDVO_TVCLKIN
SDVO_CTRLCLK B17 A17 PEG_RXN[15] / SDVO_TVCLKIN#
GND B18 A18 GND
PEG_TXP[14]/SDVOB_GREEN B19 A19 NC
PEG_TXN[14]/SDVOB_GREEN# B20 A20 GND
GND B21 A21 PEG_RXP[14]/SDVOB_INT
GND B22 A22 PEG_RXN[14]/SDVOB_INT#
PEG_TXP[13]/SDVOB_BLUE B23 A23 GND
PEG_TXN[13]/SDVOB_BLUE# B24 A24 GND
GND B25 A25 PEG_RXP[13]/SDVO_FLDSTALL
GND B26 A26 PEG_RXN[13]/SDVO_FLDSTALL#
PEG_TXP[12]/SDVOB_CLKP B27 A27 GND
PEG_TXN[12]/SDVOB_CLKN B28 A28 GND
GND B29 A29 PEG_RXP[12]
NC B30 A30 PEG_RXN[12]
SDVO_CTRLDATA B31 A31 GND
GND B32 A32 NC
PEG_TXP[11]/SDVOC_RED B33 A33 NC
PEG_TXN[11]/SDVOC_RED# B34 A34 GND
GND B35 A35 PEG_RXP[11]
GND B36 A36 PEG_RXN[11]
PEG_TXP[10]/SDVOC_GREEN B37 A37 GND
PEG_TXN[10]/SDVOC_GREEN# B38 A38 GND
GND B39 A39 PEG_RXP[10]/SDVOC_INT
GND B40 A40 PEG_RXN[10]/SDVOC_INT#
PEG_TXP[9]/SDVOC_BLUE B41 A41 GND
PEG_TXN[9]/SDVOC_BLUE# B42 A42 GND
GND B43 A43 PEG_RXP[9]
GND B44 A44 PEG_RXN[9]
PEG_TXP[8]/SDVOC_CLKN B45 A45 GND
