KTD-00782-I KTQ45 family Page 2 of 92
Document revision history.
Rev. Date By Comment
I Oct. 31 st 2013 MLA
Added System Sensor position to pictures. Battery Type no. replaced.
Added warning using PCIe Riser. Added more info on BIOS “USB
Function”. Added BIOS feature "Low RPM Fan Range".
H July 14 th 2011 MLA
Corrected version of the Standard 60950-1. Page 71 correction. Added
BIOS setting “C1E Support” and “Intel VT-d”. New pictures.
G Dec. 23 rd 2010 MLA
Corrected maximum RAM support. Note for using 820982 corrected.
ADD2-CRT support added. Chapter 2.4 corrections. Added note for using
both Onboard Graphics and PCIe card. Added note about using SATA
converter.
F Feb. 25 th 2010 MLA
Added note on Memory Remap Feature. ATX+12V pining corrected.
Chapter 2.5 updated. Other minor corrections.
E Nov. 25 th 2009 JSE/MLA Connector list corrected. CPU list correction. Table page 17 corrected.
Page 36 (& 12), RS485 description & Note 1 changed.
D Nov. 17 th 2009 MLA Added/corrected info about ETHER1/ETHER2. RAM PN corrected.
C Oct. 12 th 2009 MLA
Memory Map corrected. JP8 info on page 36 corrected. Added “mounting
the board to chassis”. PCIe x4 standard 1.1 added.
B Sep. 22 nd 2009 MLA
On page 18: DDR2 corrected to DDR3. Other minor corrections. BIOS
part updated and new layout.
A Aug. 21 st 2009 MLA Layout improvements. Minor additions.
0 July 9 th 2009 JSE/MLA Initial release
Copyright Notice:
Copyright  2007, KONTRON Technology A/S, ALL RIGHTS RESERVED.
No part of this document may be reproduced or transmitted in any form or by any means, electronically or
mechanically, for any purpose, without the express written permission of KONTRON Technology A/S.
Trademark Acknowledgement:
Brand and product names are trademarks or registered trademarks of their respective owners.
Disclaimer:
KONTRON Technology A/S reserves the right to make changes, without notice, to any product, including
circuits and/or software described or contained in this manual in order to improve design and/or
performance.
Specifications listed in this manual are subject to change without notice. KONTRON Technology assumes no
responsibility or liability for the use of the described product(s), conveys no license or title under any patent,
copyright, or mask work rights to these products, and makes no representations or warranties that these
products are free from patent, copyright, or mask work right infringement, unless otherwise specified.
Applications that are described in this manual are for illustration purposes only. KONTRON Technology A/S
makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification.
