1.5 Technical Specifications
*
+125°C is the re-bake temperature. For extended storage times greater than 24 hours, +85°C
should be the maximum.
* Operational Configuration: All available channels in operation except where otherwise
noted.
Table 1-2: CP930 Main Specifications
GROUP TYPE DESCRIPTION
CONTROLLER
Marvell Ethernet Switch
controller 88E6063-RCJ • Provides up to five channels Fast Ethernet including PHY
• Ethernet standards supported: 10Base-T, 100Base-TX, 100Base-FX
External
Interfaces
Ethernet copper Up to five, 8-contact, female, RJ45 connector(s)
Supports up to five channels of full or half duplex 10Base-T,
100Base-TX Ethernet operation up to 100 meters cable length.
Ethernet fiber optic one optional , MT-RJ type fiber optic, transceiver connector
Supports one channel of full duplex 100Base-FX Ethernet opera-
tion up to 2 kilometres link length.
Power Connector • CompactPCI
• Molex connector
Indicators
Front Panel LED One green and one yellow LED per channel for indicating
Ethernet channel operational status:
• ACT:
yellow: indicates channel activity and link
• SPEED: green: indicates Ethernet link speed, 10 Mbps or
100 Mbps
General
Mechanical Conforms with IEEE1101.1
Power Requirements board power supply:5 V, + or - 5%
Power Consumption See Table 1-3 for details
Temperature Range Operational: 0ºC to +70ºC Standard (see note)
-40°C to +85ºC
Storage: -55°C to +125ºC
*
Humidity 0% to 90% non-condensing
Dimensions 100mm x 160mm single height Eurocard
Board Weight 150 grams, 250 grams in the case of the FD variant
Table 1-3: CP930 Power Consumption
VARIANT
POWER CONSUMPTION AT (typical)
OPERATIONAL CONFIGURATION *
NO LINK 10 MBITS 100 MBITS
CP930 0,65W 1,3W 2,2W
CP930-RJ 0,65W 1,3W 2,2W
CP930-FX 2,3W 2,9W 3,6W
CP930-FD 0,65W 1,3W 2,2W
