3 board layout, Board layout - 7, Cp930 board layout - 7 – Kontron CP930 User Manual
Page 23: Cp930 introduction
CP930
Introduction
ID 26683, Rev. 01
© 2003 Kontron Modular Computers GmbH
Page 1 - 7
1.4.3
Board Layout
The following figure shows the board layout for the above indicated variants of the CP930.
Figure 1-2: CP930 Board Layout
CON3
ETHERNET
SWITCH
CONTROLLER
ETHERNET
CONNECTOR
CON5
VOLTAGE REGULATORS
OSCILLATOR
CON4
MAGNETICS
MAGNETICS
CON6
