To avoid further blockage:
• When juicing hard or stringily fruit or vegetables choose a high speed.
• Remove very hard and stringily elements such as stalks and stems.
• Try slower juicing action by pushing the food pusher down more slowly.
• Avoid overloading pulp in the pulp container. The pulp has to be able to fall easily
and unhindered into the pulp container.
• Try other fruit and vegetables.
TROuBle ShOOTinG GuiDe
Possible problem easy solution
Machine will not work
when switched ´ON´
The safety locking arm may not be correctly engaged in the verti-
cal operating position with the locking arm located into
the two grooves on either side of the juicer cover (regard
´Assembling the appliance)`.
Motor appears to stall
when juicing
Wet pulp can build up under the cover if the juicing action
is too vigorous. Try slower juicing action by pushing the food
pusher down more slowly. Clean the integrated pulp container,
the stainless steel filter basket and the juicer cover (regard ´Clear
blockage`).
Excess pulp building up
in the micro mesh filter
basket
Stop the juicing process. Remove the juicer cover, scrape off
pulp. Re-assemble and begin juicing again. Try alternating
(soft and hard) vegetable and fruit varieties.
Pulp too wet and
reduced extracted juice
Try a slower juicing action by pushing the food pusher down
more slowly. Remove stainless steel filter basket and thoroughly
clean mesh walls with the nylon brush. Rinse the stainless steel
filter basket under hot water. If the fine mesh holes are blocked,
soak the stainless steel filter basket in a solution of hot water with
10% lemon juice to unblock the holes or wash in the dishwasher.
This will remove excess fibre build up (from fruit or vegetables)
which could be inhibiting the juice flow.
Juice leaks between the
rim of the juicer and the
cover of the filter
Try a slower juicing action by pushing the food pusher down
more slowly. Fruit and vegetables with a high water content
(tomatoes and watermelon) should be juiced on low speed.
Bowl surround juice
sprays out from spout
Try a slower juicing action by pushing the food pusher down
more slowly.
Juicer makes loud noise
when turned on
Filer basket is not properly snapped into position. Turn the On/
OFF button to OFF. Turn the power OFF. Disassemble the Design
Juicer Advanced Pro (refer to ´disassembling`).
Re-assemble (refer to ´assembling`).
No juice coming out
while
juicing
Check that the spout is not blocked with pulp. Refer to ´Care and
cleaning`.
45
