empty the Pulp Container During juicing

The pulp container can be emptied during juicing by turning the appliance ‘Off’ at the control

panel and then carefully removing the pulp container. Remove the pulp container by tilting the

pulp container slightly to the right and unlatch it from under the juicer cover and the container

support extending from under the motor base. Replace the empty pulp container into position

before continuing to juice.

Overload Protection Button

The Design Juicer Advanced Pro is fitted with a safety device which safe-

guards against overheating with excessive loads. If this occurs, the juicer

will automatically activate the overload protection button and the unit will

switch itself off. If this occurs turn the power OFF at the power outlet and

allow the unit to cool. Then press the overload protection button found on

the bottom of the motor base. The safety device will then be reset and the

juicer is ready for use again.
imPORTAnT: Put aside the juice jug and the pulp container before you turn the motor base

around carefully to activat the overload protection button. The juicer is ready for use and you

can continue juicing after putting the pulp container and the juice jug back into position. In

case overload protection button gets activated straight away again refer to the trouble shoot-

ing guide.

Disassembling our Design juicer Advanced Pro
wARninG:

Always turn the appliance off and pull the plug

when the appliance is not in use or when disassembling, mov-

ing or cleaning the appliance.
Step 1:

Ensure the appliance is turned off by pressing the Off’-switch

on the control panel and unplug the cord.

Step 2:

Remove the pulp container by tilting the pulp container slightly

to the right and unlatch it from under the juicer cover and the

container support extending from under the motor base (picture

A).
Step 3:

Use the grip handle located on the safety locking arm to lift

the locking arm from the juicer cover and lower down out of

position (picture B).
Step 4:

Lift the juicer cover off the juicer (picture C).
Step 5:

Remove the filter bowl surround with the stainless steel filter

basket still in place. To remove the filter bowl hold the base of

the juicer and turn the filter bowl surround by the juice spout

clockwise (picture D).
