Page 20 HI-3520 Manual
6.3 Test Data Sheet Model HI-3520
DATE SERIAL NUMBER TESTED BY
STEPS 2.0 AND 3.0
FREQUENCY (GHz) POWER DENSITY LEVEL (mW/cm 2
1.4
2.45
3.8
8.0
12.0
18.0
STEP 4.0 P
CAL
= (P
HI
X P
LO
) 1/2 =
STEP 5.0 M = 0.2 =
P CAL
STEP 6.0 CAL FREQ =
STEP 7.0 P
REF
= M (POWER DENSITY AT CAL FREQ)
=
STEP 9.0 ALARM SET FOR P
REF
CHECK
