ETS-Lindgren 5503 Electric Field Generator - Manual (Page 29)

Operation | 29
M ODEL 5503-2M & 5503-3M: E-M ODE O PERATION
The E-field is
generated
when the two
elements are
parallel with
the ground
plane.
1. Connect E-field low power balun box to generator unit. See page 26 for
the steps to change a balun box.
2. Rotate the elements to E-field position. See page 28 for the steps to rotate
the elements.
3. Verify that the cables from the elements are connected to the generator
unit.
4. Attach the RF or power input cable to the connector on the balun box.
