20 | Operation
The pegs are installed
through the masts to hold
the carrier in any of the
three preset positions. The
carrier handle (knob) on
each carrier can be turned
to clamp the carrier at other
heights on the masts.
To raise or lower elements:
1. Remove the peg.
2. Loosen the knob.
3. Adjust the height.
4. Re-insert the peg for the desired height.
5. Tighten the knob.
Model 5503-5M E-Mode / H-Mode
The Model 5503-5M E&H Field Generator includes a high power balun box for
either E-field or H-field operation. The connectors and posts on the box are
labeled according to the type of operation that the generator will perform.
